Two Spindles With Boring Unit CNC Nesting Machine
The controlled cutting machine has two spindles and is equipped with a 5+4 CNC drilling bag, which can realize the function of rapid hole arrangement when producing panel furniture. The two spindles are high-power 6KW spindles specially responsible for cutting and slotting, and the drilling bag is specially used for drilling. In this way, the hole size encountered in the production of panel furniture can be handled. Double-spindle drilling package CNC cutting machine is also suitable for the production of batch cabinets. It is a high rate machine, and the cutting quantity is twice that of the four processes a day.
Description
CNC router machine photos
cnc router machine advantage
1. Improve sheet utilization:
With the milling cutter, the direction can be turned at will, and special shapes are no longer necessary. In the past, the pusher saw saw saw the material with one blade to the end, the plate utilization rate is low, the special shape cannot be cut, and the efficiency is low. The rapid carving CNC cutting machine is automatically optimized by self-developed software, and the average utilization rate of each plate is 2.85-2.96 square meters.
2. Labor saving:
Several sets can be operated by one person, which can be used in conjunction with the edge banding rotary line. Only one person is required to operate the opening and edge banding (limited to automatic loading and unloading machine).
3. Reduce labor intensity
Adopt more perfect intelligent production and move towards more perfect intelligent production demand.
4. Fast opening speed
This type of cutting equipment can be continuously produced. It adopts automatic tool change processing, with fast processing speed and high plate utilization rate!
5. The dust of the stripper is small
More equipped with dust removal equipment, improving the quality of production environment! Reduce equipment dust.
6. Automatic loading and unloading is fully automatic
Is an optional feature. 150-200 square meters for 8 hours a day. The common feeder is 120-150 square meters per day for 8 hours, and it is loaded and unloaded manually. During processing, people can rest in the middle, greatly reducing labor intensity
Our advantage
Thick steel welded bed structure with thick gantry bar
9KW air cooling spindle hQD brand
Auto pushing device
7.5KW vacuum pump
Can calibrate the tools
we build our company in this year. we are a professional manufacture to produce cnc router machine laser machines, plasma cutting machines, etc
We have exported machines to many countries, for example, asia, africa, america, we all have customers and distributors
We have did this exporting job for more than 10 years, now we also have fiber laser cutting machine, fiber laser welding machine, fiber laser marking machine, etc
cnc router machine specification
Model | ZK 1325 TWO SPINDLES WITH BORING UNIT CNC NESTING MACHINE |
X,Y axis travel | 1300x2500mm,option:1500*3000mm;2000*3000mm;2100*4000mm,etc |
Z axis travel | 200mm |
Spindle type | HQD 9.0KW ATC air cooling spindles with 5+4 serial boring unit to drill vertical holes
|
Inverter type | 11kw Fuling inverter |
Control system | Shanghai WEIHONG or Taiwan SYNTEC control system |
Driving system | Shanghai WEIHONG or Taiwan SYNTEC servo motor and driver |
Reducer | Japan Shimpo reducer |
Machine structure | Heavy duty body with quenching treatment |
Work table | Full-page vacuum working table |
Linear guide | Taiwan High precision Linear guide |
Transmission | X, Y axis: Taiwan / Germany Helical Rack and Pinion Z axis: Taiwan TBI high precision ball screw |
Lubrication system | 1.5L automatic lubrication system |
Tool calibration | Auto tool sensor |
Compatible software | Artcam, Hisoon, etc |
Command language | G Code |
Traveling speed | 80m/min |
Working speed | 0-25m/min |
Re-positioning accuracy | ±0.03mm |
Working accuracy | ±0.03mm |
Working voltage | 220V 1PH/3PH 50HZ/60HZ 380V 3PH 50HZ/ 60HZ |
cnc router machine application
panel furniture, cabinet body, wardrobe body, customized furniture, office furniture and other industries.
Main functions:
automatic tool change, cutting, milling, hollowing, slotting, punching, etc.
package Photos
Customers Feedback
cnc router machine video
